THREE IN ONE INVERTER
The ISI-501 Series DC/AC True Sine Wave Inverter with MPPT (maximum power point tracking) solar charger built in the control box has a microprocessor for digital control and is designed with the high frequency (HF) technology. It is a high-performance inverter that can be used with the solar panel and battery packs as a voltage converter for AC voltage output.
The built-in ISI-501 Series products can supply 500 W AC power to the load for a long period. It is able to supply 550 W for 1min very soon and can withstand the instantaneous peak load of 1000 W for up to 30 power cycles.
The built-in ISI-501 Series products are designed with the HF technology and can greatly reduce the product weight and improve the conversion efficiency, with a maximum efficiency up to 88%.
The built-in ISI-501 Series products are solar chargers with the MPPT function. They can effectively utilize the electric power supplied by solar energy.
This product can only be used with solar energy, battery, and mains power. If the mains power is not available, it is necessary to order a control box for pure solar energy and battery application.
The built-in ISI-501 Series products can supply 500 W AC power to the load for a long period. It is able to supply 550 W for 1min very soon and can withstand the instantaneous peak load of 1000 W for up to 30 power cycles.
The built-in ISI-501 Series products are designed with the HF technology and can greatly reduce the product weight and improve the conversion efficiency, with a maximum efficiency up to 88%.
The built-in ISI-501 Series products are solar chargers with the MPPT function. They can effectively utilize the electric power supplied by solar energy.
This product can only be used with solar energy, battery, and mains power. If the mains power is not available, it is necessary to order a control box for pure solar energy and battery application.
- Company NameSUN MINES ELECTRICS CO., LTD
Rated output of 500 W
The maximum instantaneous output power is up to 1000 W.
Pure sine wave output (THD<3%)
AC output voltage stability factor: ±3%
The highest working efficiency is up to 88%.
MPPT conversion efficiency (typical value) of the built-in solar charger: 98%
LED indicators show the operating state and the battery capacity.
Low battery voltage warning (with the dry contact for electrical isolation)
Remote power ON/OFF function
10. The built-in ISI-501 Series products are designed to comply with the FCC/CE regulations.
The maximum instantaneous output power is up to 1000 W.
Pure sine wave output (THD<3%)
AC output voltage stability factor: ±3%
The highest working efficiency is up to 88%.
MPPT conversion efficiency (typical value) of the built-in solar charger: 98%
LED indicators show the operating state and the battery capacity.
Low battery voltage warning (with the dry contact for electrical isolation)
Remote power ON/OFF function
10. The built-in ISI-501 Series products are designed to comply with the FCC/CE regulations.
